| تقنية: | منسوج | مادة: | أسلاك الفولاذ المقاوم للصدأ ، 316304 |
|---|---|---|---|
| نمط نسج: | نسج عادي / نسيج قطني طويل | اسم المنتج: | مربع منسوج 4 × 4 دقيق 100 ميكرون شبكة أسلاك الفولاذ المقاوم للصدأ |
| قطر السلك: | متطلبات | عرض: | عادة 1 مليون |
| بريد إلكتروني: | devin@industrialmetalmesh.com | واتساب: | +8615369013183 |
| إبراز: | 304 stainless steel woven wire mesh,316L stainless steel wire mesh,200 mesh stainless steel screen |
||
100/150/180/200 Mesh Ss 304 316 316L Stainless Steel Woven Wire Mesh
Stainless steel woven wire mesh is crafted by weaving stainless steel wires to create either square or oblong openings. With properties such as acid and alkali resistance, temperature resistance, and wear resistance, stainless steel woven mesh has become widely utilized across various industries in recent years.
Stainless steel is one of the most commonly used materials for woven wire mesh due to its superior chemical resistance, ability to handle hot or cold liquids, and ease of cleaning. Popular stainless steel grades for producing woven wire mesh include 201/304/304L/316/316L and 430.
|
Table: Specification of Plain Weave Mesh
|
||||||
|
Model
|
Mesh Count
|
Wire Diameter
|
Mesh Opening
|
Open Area
|
||
|
-
|
(Warp × Weft)
|
Inch
|
mm
|
Inch
|
mm
|
%
|
|
HJ-0185
|
1x1
|
0.0799
|
2.030
|
0.9200
|
23.37
|
85
|
|
HJ-0276
|
2x2
|
0.0629
|
1.600
|
0.4370
|
11.1
|
76
|
|
HJ-0370
|
3x3
|
0.0539
|
1.370
|
0.2791
|
7.09
|
70
|
|
HJ-0456
|
4x4
|
0.0629
|
1.600
|
0.1870
|
4.75
|
56
|
|
HJ-0563
|
5x5
|
0.0409
|
1.040
|
0.1590
|
4.04
|
63
|
|
HJ-0662
|
6x6
|
0.0350
|
0.890
|
0.1318
|
3.35
|
62
|
|
HJ-0860
|
8x8
|
0.0279
|
0.710
|
0.0968
|
2.46
|
60
|
|
HJ-1056
|
10x10
|
0.0251
|
0.640
|
0.0751
|
1.91
|
56
|
|
HJ-1258
|
12x12
|
0.0200
|
0.508
|
0.0629
|
1.60
|
58
|
|
HJ-1446
|
14x14
|
0.0229
|
0.584
|
0.0480
|
1.22
|
46
|
|
HJ-1651
|
16x16
|
0.0179
|
0.457
|
0.0444
|
1.13
|
51
|
|
HJ-1848
|
18x18
|
0.0170
|
0.432
|
0.0385
|
0.98
|
48
|
|
HJ-2046
|
20x20
|
0.0159
|
0.406
|
0.0338
|
0.86
|
46
|
|
HJ-2444
|
24x24
|
0.0140
|
0.356
|
0.0275
|
0.70
|
44
|
|
HJ-3053
|
30x30
|
0.0090
|
0.229
|
0.0244
|
0.62
|
53
|
|
HJ-4036
|
40x40
|
0.0100
|
0.254
|
0.0149
|
0.38
|
36
|
|
HJ-5037
|
50x50
|
0.0079
|
0.203
|
0.0122
|
0.31
|
37
|
|
HJ-6034
|
60x60
|
0.0070
|
0.178
|
0.0098
|
0.25
|
34
|
|
HJ-8032
|
80x80
|
0.0055
|
0.140
|
0.0070
|
0.18
|
32
|
|
HJ-10037
|
100x100
|
0.0039
|
0.100
|
0.0060
|
0.154
|
37
|
|
HJ-12033
|
120x120
|
0.0035
|
0.090
|
0.0047
|
0.121
|
33
|
|
HJ-15042
|
150x150
|
0.0024
|
0.060
|
0.0042
|
0.109
|
42
|
|
HJ-16546
|
165x165
|
0.0019
|
0.050
|
0.0040
|
0.104
|
46
|
|
HJ-18042
|
180x180
|
0.0019
|
0.050
|
0.0036
|
0.0911
|
42
|
|
HJ-20034
|
200x200
|
0.0021
|
0.053
|
0.0029
|
0.0740
|
34
|
|
HJ-25037
|
250x250
|
0.0015
|
0.040
|
0.0024
|
0.0616
|
37
|
|
HJ-30033
|
300x300
|
0.0014
|
0.036
|
0.0019
|
0.0487
|
33
|
|
HJ-32531
|
325x325
|
0.0013
|
0.035
|
0.0017
|
0.0432
|
31
|
|
HJ-35034
|
350x350
|
0.0011
|
0.030
|
0.00167
|
0.0426
|
34
|
|
HJ-40028
|
400x400
|
0.0011
|
0.030
|
0.00131
|
0.0335
|
28
|
|
HJ-50026
|
500x500
|
0.00098
|
0.025
|
0.00101
|
0.0258
|
26
|
|
HJ-63525
|
635x635
|
0.00078
|
0.020
|
0.00078
|
0.0200
|
25
|
|
*We have more types of mesh than what is shown on the chart. Please feel free to contact us if you are looking for a certain opening size.
|
||||||
Other things you need to know about 316 stainless steel mesh
When ordering the 316L stainless steel wire cloth, please specify the mesh count, wire diameter, hole size, weave type, mesh width, and length.
For example:
SS316L Screen Mesh 120 x 3′ x 100′ x 0.08mm Inquiry
SS316L Screen Mesh 100 x 3′ x 100′ x 0.1mm Inquiry.
More specifically such as:
Stainless steel mesh 316L, DTW 200/600, 40inch, 30meter , 1 roll
SUS 316L mesh, DTW 10 micron 200 x 1400 mesh, 0.07/ 0.04mm, size: 1m x 30m, 1 roll
2. Deep processing services
The wire mesh ss316 can be cut into different shapes of sheets, It can also be processed into filter tubes and filter caps.
For example, SS316L Screen Mesh 20 x 4 feet x 6 feet Long sheet, or SS316L Screen Mesh 60 x 59mm diameter Circular.
It can also be slit, for example, 200 mesh ss316 wire mesh can slit into 500mm width, and there will be 2 cutting rolls from 1m width 200 mesh 316 stainless steel mesh.
3. Detail application example
325 mesh 0.035mm wire diameter twill weave 316L stainless steel mesh used for stainless steel filter cartridge production.
300 mesh, 350 mesh, 400 mesh, 500 mesh Plain weave 316L stainless steel wire mesh used as screen printing mesh in Glass, ceramics, metals, plastics, rubber, and printed circuits industries.
24/110 mesh Dutch weave 316L stainless steel mesh used in the production of sunflower oil.
